Long Back-up Online Modular UPS Power Supply for Industry 10-800KVA

China Long Back-up Online Modular UPS Power Supply for Industry 10-800KVA supplier

Large Image :  Long Back-up Online Modular UPS Power Supply for Industry 10-800KVA

Product Details:

Place of Origin: China
Brand Name: SOROTEC
Certification: CE,ROHS,RSO9000
Model Number: MPS9335C 10-800KVA

Payment & Shipping Terms:

Minimum Order Quantity: 2PCS
Price: USD10000
Packaging Details: Standard Exported Cartons and Pallets
Delivery Time: Within 15-30days after receiving your 30% TT deposit
Supply Ability: 10000PCS/Month for Inverter and line Interactive UPS; Advance 3000PCS/Month for Online UPS
Contact Now
Detailed Product Description
Model: Modular UPS Capacity: 10-800KVA
Large Power UPS: Yes Input Voltage: 380/400/415VAC
Output Power Factor: 1.0 Nominal Frequency: 50/60HZ
3-Phase 4-Wire: Yes Current Crest Ratio: 3:1
THDI: <3% LCD Display: 13 Languages
Support Hot Swappable: Yes Superior Energy Saving: Yes
Applacation: Data Center,Telecom,Finance Bank,Securities,Hospital Sistems,Industry Automation.etc

Long Back-up Online Modular UPS Power Supply for Industry 10-800KVA



Key Features:



1.Superior energy saving and environment-friendly: Efficiency > 96% at 50%-75% rated load, and > 95% at 25% rated load; Input PF > 0.99,input THDi<3%



2.Superior capability of powering load: Output PF is 0.9, no need of power deration with load of leading or lagging PF



3.Easy-to-install: Top or bottom cabling, no need of input cabling cabinet.



4.Easy-to-maintain: Full front access, UPS, failed part can be replaced shortly



5.Easy-to-modify: The number of battery cells can be configured flexibly, so the original batteries can be used when modifying the legacy system; moreover, the battery cell can be replaced in time when it fails without interrupting the normal operation of UPS.



6. 6-inch extra large LCD that can display 12 language ( Chinese,English , Russian , Spanish , French and so on )



7.touch screen optional



UPS Modules:

0.9 Power factor Can Display 12 Language Modular UPS 10-300KVA MPS9335C 0.9 Power factor Can Display 12 Language Modular UPS 10-300KVA MPS9335C





Application:

ApplicationIDC(Internet Data Center), computing center, ISP (Internet Service Provider ),Telecom,Finance bank and securities, Tax, hospital system, industrial automation, precision equipment, etc.





Technical Specifications of Modular UPS, MPS9335 10-300KVA:

Model MPS9335 10-300KVA
Capacity 10-300KVA
Main input
Input voltage 380V/400V/415AC(Optional South America 208v)
Input Frequency Range 50/60Hz
Power Factor Full load>0.99 ,Half load >0. 98
THDi THDi <3%
Input power soft-start fantion 5-30s settable
Input Voltage Ranges 228V-476V-20%- +25% Full load linear derating at -25% - -40%; can take 70% load at -40%
Frequency Range 40-70Hz
Battery
Battery Voltage ±240VDC(Default),12V Battery30-40pcs can be choose
Charge Voltage accuracy ± 1%
Bypass
Bypass Input voltage 380/400/415VAC 3-phase 4-wire
Voltage Ranges Default value is -20%-+15%, -40%, -30%, -10% - +10%, other ranges can be set via software
Overload Capacity 150%,long term operation,150%<load<180%,more than 1 hour ,load>1000% 100ms
Output
Inverter Output Voltage 380/400/415VAC 3-phase 4-wire
Voltage Accuracy ± 0.5%(balanced load), ± 1% (unbalanced load)
THDi THD<1%(linear load), THD<3%(nonlinear load)
Power Factor 0.9
Three Phase Angle accuracy 120°c ± 0.5°c
Current Crest Ratio 3:1
Overload Capacity 110%1h,125%10mins,150%1mins,>150%200ms
Transfer Time 0ms,15ms(ECO Mode)
System
Frequency 50Hz/60Hz (Settable)
Mains synchronization range ±2Hz(Default value) adjustable with step of 0.5Hz within range of +/- 0.5Hz - 3Hz
Protection Level IP20
Communication Ports RS232,RS485,dry contact,SNMP card,EPO,generator port
System efficiency > 96% at load above 50%, >95% at load above 25%
Operation Temperature 0-40 °c
Storage Temperature -25 °c -70 °c (without battery)
Humidity 0-95%(no-condensing)
Noise(dB) 55-62dB,Adjusted with load
  5 module cabinet module :RMS050/10, RMS100/20, RMS150/30 150KG
  10 module cabinet module :RMS100/10, RMS200/20, RMS300/30 150KG
  module :PM10 10KVA power module :20KG
Weight module :PM20 20KVA power module :21KG
  module :PM30 30KVA power module :32KG
Dimendion(W XD XH)mm 5 module cabinet 600X1400X850
10 module cabinet 600X2070X850
power module 440X132X660(10KVA/20KVA/30KVA)



0.9 Power factor Can Display 12 Language Modular UPS 10-300KVA MPS9335C

0.9 Power factor Can Display 12 Language Modular UPS 10-300KVA MPS9335C
