10KVA 380VAC Three Phase High Frequency Online UPS Power Supply with 240VDC Battery

China 10KVA 380VAC Three Phase High Frequency Online UPS Power Supply  with 240VDC Battery supplier

Large Image :  10KVA 380VAC Three Phase High Frequency Online UPS Power Supply with 240VDC Battery

Product Details:

Place of Origin: Shenzhen,China
Brand Name: SOROTEC
Certification: CE,ROHS,RSO9000
Model Number: HP9316CR 10KVA

Payment & Shipping Terms:

Minimum Order Quantity: 2PCS
Price: USD10000
Packaging Details: Standard Exported Cartons and Pallets
Delivery Time: Within 15-30days after receiving your 30% TT deposit
Supply Ability: 10000PCS/Month for Inverter and line Interactive UPS; Advance 3000PCS/Month for Online UPS
Contact Now
Detailed Product Description
Product: High Frequency Online UPS Model: HP9316CR
Capacity: 10KVA/7KW Phase: Three Phase
Input Voltage Range: 304~478VAC(±3VAC) Output Power Factor: 0.7/0.8(optional)
Transfer Time: 0ms(AC→DC) Battery Voltage: 240VAC
Charging Current: 2.0A/4.2A/5.6A(Option) Frequency: 50/60HZ
Display: LCD Display Communications Port: RS232, SNMP Card(option, USB Port(option)
Temperature: 0~40℃ Elevation: <1500 Meter
Wide Input Voltage Range: Support Parallel Operation: Yes
Application: Personal Computer,telecom,emergency Devices.etc OEM Or LOGO: Available
Wave Form: Pure Sine Wave

10KVA 380VAC Three Phase High Frequency Online UPS Power Supply with 240VDC Battery



HP9116CR series rack mount UPS is a pure sine wave online UPS power supply, the capacity from 1kva to 10kva.  Compared to line interactive or offline UPS, online UPS can provide the best power environment for the load and it is the best UPS structure considering from the voltage regulation, output range, frequency range, input noise filter, and utility model to battery mode zero transfer time.



Key Features:

1.blue large LCD display interface in English,user-friendly



2.pure high frequency online UPS,with voltage adjustment circuit, provide stable power protection in bad operation environment



3.comprehensive electrical isolation protection and bypass protection



4.input power factor correction, reduce the harm of harmonic on grid,convenient to match small generators



5.automatic alarm, self test function



6.wide input voltage range



7.Input neutral and live wire detection function and data protection function



8.Main power failure,going to DC staring , Convenient and reliable; Main power recover,UPS start automatically



9.N+X Parallel Redundancy and Capacity expansion for 6K-10K



Technical Specifications of Rack Mount UPS HP9116CR HP9316CR 1-10KVA


Model
HP9116CR 1-10KVA HP9316CR 10KVA
1KR/1KR-XL 2KR/2KR-XL 3KR/3KR-XL 6KR/6KR-XL 10KR/10KR-XL 10KR/10KR-XL
Capacity 1KVA/800W 2KVA/1600W 3KVA/2400W 6KVA/4800W 10KVA/8000W 10KVA/8000W
Nominal Voltage 220/230/240VAC 380VAC
Frequency 50/60 Hz
Input
Voltage Range 115~295VAC(±3VAC) 176~297VAC(±3VAC) 304~478VAC(±3VAC)
Frequency Range 50HZ:(46~54HZ);60HZ:(56HZ~64HZ)
Power Factor >0.98
Output
Voltage precision 220/230/240X (1±2%)VAC
Frequency precision 50/60HZ±0.05Hz
Power Factor 0.7/0.8(option)
Harmonic Distortion Linear Load<3% Non-Linear Load<6%
Overload capacity overload(110%~150%)after 30 seconds automatically transfer to bypass, it recover after normal load
Current Crest Ratio 3:1
Transfer time 0ms(AC→DC)
Battery
DC voltage 36VDC 96VDC 240VDC
Recharge time 5 hours to 90%
Charge Current 1A 4A 1A 8A 1A 8A 2.0A/4.2A5.6A(option)
Panel Display
LCD Display input and output voltage, frequency, battery voltage, battery capacity, and the percentage of load
Communicate
Communicate interface RS232, SNMP card(option, USB port(option)
Working Environment
Temperature 0~40℃
Humidity 0~95% non-condensing
Storage Temperature -25℃~55℃
Elevation <1500 meter
Noise Level(1meter) <45dB <50dB
Physics Characteristic
Weight(KG) N.W 16.5 9 26 11.5 26 12.5 18.5 18.5 25 32 25 32
G.W. 18.5 11.5 28 14.5 28 15 21.5 21.5 28.2 35 28.2 35
Dimension (WXDXH)

447x450

x130

447x600

x130

447x450

x130

447x600

x130

447

x450x130

447 x600x130 447x600x177



















Application:
This series against the key equipment, such as special communication system and computer network system,and provide more flexible and reliable power protection for equipments require strict environment of power .





10KVA 380VAC Three Phase High Frequency Online UPS Power Supply  with 240VDC Battery



Trendy & Elegant LCD Design for real-time UPS system information
Rack Mount UPS HP9116CR HP9316CR 1-10K
