Single Output 230VAC grid tie solar power inverter with battery backup for house

Minimum Order Quantity : 1pcs Price : 150-300 USD Per Unit
Packaging Details : Standard Exported Cartons and Pallets Delivery Time : Within 15-30days after receiving your 30% TT deposit
Payment Terms : L/C, T/T, Western Union Supply Ability : 5000PCS Per Month
Place of Origin: China Brand Name: SOROTEC /OEM
Certification: CE,ROHS,RSO9000 Model Number: SSP3118C1 1-5KVA

Detail Information

Product Name: Pure Sine Wave Solar Power Inverter Output Type: Single
Capacity: 1-5KVA Waveform: Pure Sine Wave
Output Voltage: 220/230V Output Current: 60A
Application: Fridge,Aircondition,Personal Computer,TV.etc Weight: 7Kg
High Light:

solar power inverter for home


home power inverter

Product Description


Single Output 230VAC grid tie solar power inverter with battery backup for house



SOROTEC SSP3118C1  is a multi-function Off-grid  Solar Power Inverter with 50Amp PWM Solar Charge Controller,which capacity from 1Kva to 5Kva. multi- Charging Priority Modes and Output Priorities available . can provide reliable long backup time ac power supply for home and office equipment such as:Fridge,Air-conditional,TV,Computer .etc





Product Features:

  • Built-in PWM solar charge controller
  • Remote panel available
  • Pure sine wave inverter
  • Cold start function
  • Auto restart while AC is recovering
  • Overload and short circuit protection
  • Compatible to mains voltage or generator power
  • Selectable charging current based on applications
  • Configurable AC/Solar input priority via LCD setting
  • Smart battery charger design for optimized battery performance
  • Parallel operation with up to 6 units only available for 4KVA/5KVA
  • Selectable input voltage range for home appliances and personal computers


Protection Function:

Protection for low battery voltage, over load, output short circuit and over- temperature Restrain surge interference, eliminate noise, protection for thunder striking, provide the reliable power to the home appliances.



Supply the reliable long back up time power for the home appliances and office appliances solar power systems etc.




SOROTEC SSP3118C1  1-5kva Series High Frequency Pure Sine Wave Solar Inverter

MODEL C1 1K-1250 C1 2K-2450 C1 3K-2450 C1 4K-4850 C1 5K-4850
Rated Power 1000VA / 800W 2000VA/1600W 3000VA / 2400W 4000VA / 3200W 5000VA / 4000W
Voltage 230 VAC
Selectable Voltage Range 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances)
Frequency Range 50 Hz/60 Hz (Auto sensing)
AC Voltage Regulation (Batt. Mode) 230VAC ± 5 %
Surge Power 2000VA 4000VA 6000VA 8000VA 10000VA
Efficiency (Peak) 90% 93%
Transfer Time 10 ms (For Personal Computers) 20 ms (For Home Appliances)
Waveform Pure sine wave
Battery Voltage 12 VDC 24 VDC 48 VDC
Floating Charge Voltage 13.5 VDC 27 VDC 54 VDC
Overcharge Protection 15.5 VDC 31 VDC 60 VDC
Maximum PV Array Open Circuit Voltage 50VDC 60VDC 105VDC
Standby Power Consumption 1 W 2 W 2W
Maxmum Solar Charge Current 50A 50A 50 A
Maximum AC Charge Current 20 A 30 A 60 A
Maximum Charge Current 50 A 50 A 110 A
Dimension, D x W x H (mm) 95 x 240 x 316 100 x 272 x 355 120 x 295 x 468
Net Weight (kgs) 5 6.4 6.9 9.8 9.8
Humidity 5% to 95% Relative Humidity(Non-condensing)
Operating Temperature 0°C - 55°C
Storage Temperature -15°C - 60°C
