230VAC Solar Power Inverters , DC / AC sine wave power inverter with 40A PWM Charger

Minimum Order Quantity : 1PCS Inverter ( Sample Are Available) Price : Negotiable
Packaging Details : Standard Exported Cartons and Pallets for solar power inverter system Delivery Time : Within 15-30days after receiving your 30% TT deposit
Payment Terms : Western Union, T/T, L/C Supply Ability : 10000PCS/Month for Inverter and line Interactive UPS; Advance 3000PCS/Month for Online UPS
Place of Origin: China Brand Name: SOROTEC
Certification: CE,ROHS,ISO9000 Model Number: SSP3111C Plus 1-2KVA

Detail Information

Product Name: DC /AC Solar Power Inverter With 40A PWM Charger Capacity: 1000~2000W
Wave Form: Modified Sine Wave Power Factor: 0.7
Nominal Voltage: 220/230/240VAC Frequency: 50/60hz
Auto Transfer: DC -AC Application: Reneable Energy
Color: Red Battery Mode To Utility: 10ms Max
High Light:

solar energy inverter

,

home power inverter

Product Description

230VAC Modified Sine Wave DC /AC Solar Power Inverter with 40A PWM Charger

SSP3111C Plus Series Off-Grid  Solar Inverter System for Home/Office Appliances
1.  High Frequency Modified Sine Wave Inverters
2.  Off-Grid Hybrid Solar Inverter
3.  Single Phase Input & Output
4.  Nominal Voltage:230VAC
5.  Input Voltage Range:170-280VAC for narrow range, 90-280vac for wide range


Key Features

1.Built-in PWM solar charge controller.

2.Modified sine wave output.

3.High frequency design.

4.Optional input voltage range.

5.Full automatic and silent operation.

6.Automatic charging.

7.Automatic transfer AC-DC

8.Over-load protection.

9.Automatic restart.

10.Three-steps intelligent charging control to recharging.

11.LCD display, audible and visual alarm.

Product Descriptions of  Solar Inverter With PWM Solar Controller

Model SSP3111C Plus 1000-2000VA
1000-12 2000-24
Capacity 1000VA/720W 2000VA/1440W
Nominal Voltage 220/230/240VAC
Nominal Frequency 50/60Hz
Input
Voltage Range 170-280VAC±4%(Narrow Range) 90Vac~280VAC±4%(Wide Range)
Frequency Range 50/60Hz
Output
Voltage Regulation 230VAC±10%
Frequency Regulation 50/60Hz±0.1Hz
Wave Form Modified Sine wave
Utility to battery mode 15-20ms typical(narrow range); 40ms max(wide range)
Battery mode to Utility 10ms max
Battery mode efficiency >80%
Line mode efficiency >95% (battery full charged)
Battery
DC Voltage 12V 24V
Overcharge Protection 16V 32V
Charge Current 15A/20A 10A
LCD Display & LED Indicate
Line mode Line mode 1, charge current >3A Green flashing every 2 seconds
Line mode 2,charge current ≦3A Green solid lighting
Off-charge mode Green flashing as cycle:
Battery Mode Yellow lighting
Overload Red flashing every 0.5 second
Fault Red lighting
SOLAR CHARGE
Maximum PV Array Open Circuit Voltage 55VDC
PV Optimal Work Voltage 15V~18Vdc 30-36Vdc
Maximum Charging Current 50A
Maximum Efficiency >96%
Standby Power Consumption <20W
Environment
Temperature 0°C~40°C
Humidity 5%-95% (<40°C, Non-condensing)
Storage Temperature -15°C~55°C
Elevation <1500m
IP Proyection level IP20
PHYSICAL
Dimension,D×W×H (mm) 298.9×250×105
Net Weight (kgs) 2.62 2.76

230VAC Solar Power Inverters , DC / AC sine wave power inverter with 40A PWM Charger 0230VAC Solar Power Inverters , DC / AC sine wave power inverter with 40A PWM Charger 1
