High Frequency Pure Sine Wave Uninterrupted Power Supply Online UPS 3KVA 220V

Minimum Order Quantity : 2PCS Price : 100USD
Packaging Details : Standard Exported Cartons and Pallets Delivery Time : Within 15-30 days after receiving your 30% TT deposit
Payment Terms : L/C, T/T, Western Union Supply Ability : 5000PCS Per Month
Place of Origin: China Brand Name: SOROTEC
Certification: CE,ROHS,RSO9000 Model Number: HP9116C PLUS 1-3KVA

Detail Information

Type: High Frequency Online UPS Model: HP9116C PLUS
Capacity: 3KVA/2.7KW Phase: Single Phase
Back Up Time: Long Time Run Wave Form: Pure Sine Wave Output UPS
Protection: Overload,Overvoltage,Short Circuit Output Power Factor: 0.9
Input Voltage: 115~300VAC (±3VAC) Output Voltage: 220/230/240VAC
Frequency: 50/60HZ Battery Voltage: 72VDC
Application: Industry Dimension(W*D*H)): 192X393X328mm
High Light:

backup power supply


ups power supply

Product Description

3KVA 220V High Frequency Pure Sine Wave Uninterruptible Power Supply Online UPS




SOROTEC HP9116C /HP9316C PLUS Series is a more reliable and higher efficiency  type High frequency online ups,which capacity from 1Kva to 20kva,can provide reliable   long back up time uninterruptable power supply for industry,telecom,data center and so on equipments. its output power factor is 0.9 can take more adopts advanced parallel technology to achieve  capacity extention max up to 3 units ups 3phase or single phase input .Support stable  frequency conversion .High efficiency up to 94% when take the loads 30%.


High Frequency Pure Sine Wave Uninterrupted Power Supply Online UPS 3KVA 220V 0



Key Features



1.Selectable  battery voltage to meet different requirements.


2.Easy to get more back up time and lower system invests.


3.High efficiency up to 94% when take 30% loads


4.High output power factor 0.9 can take more loads


5.Intelligent battery monitors and  charge current adjustable


6.Support three phase input or single phase input ,input THDI<5%


7.Advanced parallel technology can parallel redundancy for 3 units

High Frequency Pure Sine Wave Uninterrupted Power Supply Online UPS 3KVA 220V 1



8.Support frequency conversion function makes the output more stable


9.Wide input voltage and frequency range adapt  bad power grid condition


10.Advanced DSP control technology guarantee the system more safe and reliable


11.Output voltage regulation 1%, frequency regulation 0.1%, parallel current sharing 1%.



12.Optional trip technology can advoid and isolation the fault ,improved system availability





Data centre,bank station,network ,office,automatic equipment,industry,

monitor equipment,communication equipment,control system and so on


Technical Parameter

Model HP9116C Plus 1-3KVA
Rated Power 1KVA/0.9KW 2KVA/1.8KW 3KVA/2.7KW
Rated Voltage 220/230/240VAC
Rated Frequency 40/70 Hz
Rated Frequency
Voltage Range 115~300VAC (±3VAC)
THDi 50HZ: (46~54HZ); 60HZ:(56HZ~64HZ)
Power Factor > 0.98
Voltage Regulation 220±2%VAC
Frequency Regulation 50/60 Hz±0.05Hz
Power Factor 0.9
Voltage Distortion Linear load<4% Non-linear load<7%
Overload Capability 110%~150% for 47-25 sec;150%~200% for 25 -300ms; >200% for 200m
Current Crest Ratio 3∶1
Transfer Time 0ms (AC mode→Battery mode)
Efficiency(on line mode) 89% 90% 90%
DC Voltage 24 VDC 36 VDC 48 VDC 72 VDC 72VDC 96VDC
Recharge Time 7hrs to 90% of capacity
Recharge Current 1A 6A 1A 6A 1A 6A
LCD Display input/output Voltage, Frequency, Battery voltag, Battery capacity, Loading rate.
Interface Smart RS232, SNMP(Optional),USB (Optional)
Operation Temperature 0~40℃
Humidity 20~90% (Non-condensing)
Storage Temperature -25℃~55℃
Sea Level Elevation <1500m
Noise Level (1m) <45dB <50dB
Physics Characteristic
Dimensions: Wx D x H )mm 145X345X229 192X393X328
