White 60HZ 3kva 48v high power inverter with 80A MPPT Controller

Minimum Order Quantity : 2PCS Price : 200-1000
Packaging Details : Standard Exported Cartons and Pallets Delivery Time : Within 15-30days after receiving your 30% TT deposit
Payment Terms : L/C, T/T, Western Union Supply Ability : 5000PCS Per Month
Place of Origin: China Brand Name: SOROTEC
Certification: CE,ROHS,RSO9000 Model Number: SSP3119C 1000-5000VA

Detail Information

Model: On / Off Grid Hybrid Solar Energy Inverter Inverter Power: 3000VA/4000W
Input Power Factor: 0.9 Battery Voltage: 48VDC
Input Voltage: 90-280VAC Or 170-280VAC Output Voltage: 220/230/240VAC
Frequency: 50HZ/60HZ (Auto-sensing) Application: Fridge,TV,Fan,Air-conditional
Solar Controller: 80A MPPT Color: White
High Light:

grid hybrid solar power inverter

,

hybrid pv inverter

Product Description



White 60HZ 3kva 48v high power inverter with 80A MPPT Controller



Product  On-Off Hybrid Solar Inverter with Battery Pack
Model SSP3119C  1000-5000VA
Color White
Output Power 3KVA/4000W
Power Factor 0.9
Parallel Working 6 Units Max .24KW
Solar Controller 80Amp mppt





Key Features:

1.Pure sine wave output
2.Self-consumption and Feed-in to the grid
3.Programmable supply priority for PV, Battery or Grid
4.User-adjustable charging current and voltage
5.Monitoring software for real-time status display and control
6.Parallel operation up to 6 units only for 3K/4K/5K models
7.Programmable multiple operation modes: Grid-tie,off-grid and grid-tie with backup



SSP3119C On and Off Grid Hybrid Solar Power Inverter technical specifications:



MODEL 3K-48 4K-48 5K-48
Max.PV Array Power 4000W 4000W 6000W
Rated Output Power 3000W 4000W 5000W
Maximum PV Array Open Circuit Voltage 145VDC 145VDC 145VDC
MPPT Range @ Operating Voltage 60~115VDC 60~115VDC 60~115VDC
MPPT Tracker Number 1 1 2
GRID-TIE  OPERATION
GRID OUTPUT(AC)
Nominal Output Voltage 220/230/240VAC
Output Voltage Range 184-264.5VAC
Nominal Output Current 13A 17A 21.7A
Power Factor >0.99
Efficiency
Maximum Conversion Efficiency (DC/AC) 90%
GRID    INPUT
Accepatable Input Voltage Range 90-280VAC    or 170-280VAC
Frequency Range 50HZ/60HZ(Auto sensing)
Maximum AC Input Current 40A
BATTERY MODE OUTPUT(AC)
Nominal Output Voltage 220/230/240VAC
Output Waveform Pure Sine Wave
Efficiency(DC to AC) 93%
BATTERY&CHARGER
Nominal DC Voltage 48VDC 48VDC 48VDC
Maximum Solar Charge Current 80A 80A 120A
Maximum AC Charge Current 60A
Maximum Charge Current 140A 140A 180A
INTERFACE
Parallel Function Yes Yes Yes
Communication USB or RS232/Dry-Contact
ENVIRONMENT
Humidity 0~90%RH (No condensing)
Operating Temperature 0 to 50℃







Protection:
Protection for low battery voltage,over load,output short circuit and over- temperature Restrain surge interference,eliminate noise,protection for thunder striking,provide the reliable power to the home appliances.



Application:

Provide long time backup ac power supply for the household appliances ,office appliances and solar power system.etc





Product Picture Show:

White 60HZ 3kva 48v high power inverter with 80A MPPT Controller 0
